30,000 L cryogenic transport semi-trailers are designed for the bulk transportation of liquefied industrial gases such as liquid nitrogen (LIN), liquid oxygen (LOX) and liquid argon (LAR). The vacuum-insulated tank helps reduce heat transfer and product loss during road transportation.
BluNet supplies cryogenic transport semi-trailers with stainless-steel inner vessels, insulated outer shells, cryogenic pumping equipment and configurations adapted to the requirements of different markets and transport applications.
30,000 L Cryogenic Semi-Trailer
The referenced model is a 30,000 L cryogenic transport semi-trailer designed for bulk transportation of liquid oxygen, liquid nitrogen and liquid argon.
The tank uses a stainless-steel inner vessel and carbon-steel outer shell. A cryogenic pump system, including inlet and outlet flexible hoses and a filter, can be integrated with the tank to support efficient loading and unloading operations.
A previously supplied configuration was exported to Saudi Arabia for liquid nitrogen transportation, providing practical project experience for cryogenic road transport applications.
| Specification | Details |
|---|---|
| Model | 9401GDYNW |
| Product Type | Cryogenic transport semi-trailer |
| Medium | Liquid nitrogen, liquid oxygen, and liquid argon |
| Nominal Volume | 30,000 L* |
| Working Pressure | 1.6 bar* |
| Inner Vessel | Stainless steel S30408 |
| Outer Shell | Carbon steel Q345R |
| Pump System | Cryogenic pump with inlet/outlet flexible hoses and filter |
| Overall Dimensions | Φ11,810 × 2,500 × 3,650 mm* |
| Design Standards | GB150 and GB/T18442* |
*Specifications refer to the referenced 30,000 L configuration. Final capacity, pressure, dimensions, equipment and applicable standards should be confirmed against the project-specific design and certification documents.
Key Features
- Vacuum-insulated tank: Designed to reduce heat ingress and help maintain stable cryogenic conditions during transportation.
- Stainless-steel inner vessel: Suitable for compatible cryogenic liquids including LIN, LOX and LAR.
- Integrated cryogenic pump: Pump, flexible hoses and filtration equipment can be configured for loading and unloading requirements.
- Road transport configuration: Tank and chassis are designed as a semi-trailer system for bulk cryogenic liquid transportation.
- Market-specific engineering: Tank dimensions, pressure rating, chassis, valves, piping and discharge equipment can be configured according to destination-market requirements.
Applications
Cryogenic transport semi-trailers are used where large quantities of liquefied gases need to be transported between production, storage and consumption locations.
Typical applications include:
- Bulk liquid nitrogen transportation
- Bulk liquid oxygen transportation
- Bulk liquid argon transportation
- Industrial gas distribution
- Cryogenic gas supply for manufacturing facilities
- Transportation between air separation plants and customer storage sites
For LNG and other cryogenic liquids, the tank design, materials, pressure rating, safety equipment and transport approvals must be selected according to the specific medium and destination market.
Design Standards and Compliance
Cryogenic transport equipment must be designed and approved according to the requirements applicable to the gas, tank design and country or region of operation.
The referenced configuration is designed according to GB150 and GB/T18442. Other configurations may be engineered according to applicable requirements such as ASME Section VIII, CGA-341, DOT/TC requirements or other destination-market regulations where applicable.
The exact standard and approval route should be confirmed during project engineering rather than assumed from the gas type alone.
Customized Cryogenic Transport Trailers
Different transportation routes and gases require different equipment configurations. BluNet can configure cryogenic semi-trailers according to requirements such as:
- Tank capacity and dimensions
- Design and working pressure
- Cryogenic liquid and material compatibility
- Vacuum and insulation system
- Chassis configuration
- Cryogenic pump and discharge equipment
- Valves, piping and safety devices
- Loading and unloading connections
- Applicable destination-market standards
For a broader selection of transport equipment, see our cryogenic tanker semi-trailer category.
30,000 L Cryogenic Semi-Trailer for Bulk Gas Transportation
The 30,000 L configuration is suitable for industrial gas suppliers and other operators requiring high-capacity road transportation of compatible cryogenic liquids. Its stainless-steel inner vessel, insulated tank construction and optional cryogenic pump system provide a practical solution for bulk distribution.
For stationary storage after delivery, see our cryogenic storage tanks. For an overview of trailer types and transportation methods, see our cryogenic transportation guide.
